USB Explorer USB 3.0 and 2.0 Test System

Short Description:

This is a PCB assembly project for USB Explorer  USB 3.0 and 2.0 Test System. At Pandawill, our tester technology understanding make us a unique partner for the instrumentation & measurement business and we are delivering solutions for leading companies in the world.


  • FOB Price: US $129/Piece
  • Min Order Quantity(MOQ): 1 PCS
  • Supply Capability:: 100,000,000 PCS per month
  • Payment Terms: T/T/, L/C, PayPal
  • Product Detail

    Product Tags

    Product Details

    Layers 14 layers
    Board thickness 1.60 MM
    Material PPO/PPE + FR4 high TG 175℃
    Copper thickness 1 OZ(35um)
    Surface Finish Immersion Gold; Au Thickness 0.05 um; Ni Thickness 3um
    Min Hole(mm) 0.20mm via plugged with solder mask
    Min Line Width(mm) 0.13mm
    Min Line Space(mm) 0.12mm
    Solder Mask Green + Black
     Legend Color White
    Board size 220*140mm
    PCB Assembly  Mixed surface mount & through hole assembly
    RoHS Complied Lead free assembly process
    Min components size 0201
    Total components 1282 per board
    IC Package BGA; QFN
    Main IC Fairchild, On Semiconductors, Maxim, ADI, Microchip, TI, , Cypress Semi, NXP etc
    Test  AOI, X-Ray, Functional test
    Application Test & measurement

    Our tester technology understanding make us a unique partner for the instrumentation & measurement business and we are delivering solutions for leading companies in the world

    > Humidity meters

    > Recorders and data loggers

    > Spectrum and signal analysis

    > Gas analysis

    > Density meters

    > Non-destructive testing (NDT) equipment

    > Diagnostic machines

    > Water and environmental test equipment

    > Filtration treatment

    > Electrical test equipment

    > Traffic data recorders

    > Metal detection

    And many more

    otal process control and reduced tolerances are hugely important for any technology where measurement is the primary product function.

    All of the circuit boards manufactured by pandawill Circuits can be supplied to IPC Class 2 or 3 standards, but more importantly, pandawill apply tighter tolerance controls that standard to ensure that all products delivered offer continuity of physical dimensions and electronics performance.

    The IPC specifications can at times be disconcertingly broad and forgiving for a manufacture of circuit boards, but the difference between top and bottom tolerance can be in the region of  20% variance. pandawill feel this is simply not enough control and is completely avoidable if suitable care is taken when selecting raw materials and manufacturing multi-layer PCBs.

    For every circuit board supplied by pandawill Circuit, we supply a several page comprehensive quality report that shows all of the physical dimensions, materials, plating depths and processes confirmation.

    The boards are also supplied with a cross section if required to show layer build and internal plating performance, and a solderability sample that indicated the wetting performance of the solderable finish and the PCB’s resistance to delamination.

    Every first batch delivered will undergo secondary inspection at the pandawill Circuits office and each pack is marked with our logo once approved.
